Certified Pre-Owned: Vetted based on “Like New” condition, 90-day minimum Seller-backed warranty , unlocked, fully functional with multi-point inspection & full data purge performed. The device looks new at first glance, upon close examination, it is possible to find some minor signs of wear.
System Information:
The chipset is integrated into the processor, featuring a 64-bit DRAM bus width and a 32 MB FLASH EPROM. The system supports PCIe Gen3 and an external bus frequency of up to 8 GT/s.
Processor:
The available processor options include:
- 8th Gen Intel Core i7-8665U: 8 MB cache, 4 cores / 8 threads, speeds ranging from 1.9 GHz to 4.8 GHz with a 15W TDP, featuring Intel UHD Graphics 620 or AMD Radeon 540X (discrete).
Memory:
The memory configuration can range from a minimum of 4 GB to a maximum of 32 GB, with two SoDIMM slots. The maximum supported per slot is 16 GB, and it operates at a speed of 2666 MHz DDR4. The system supports a variety of memory options, such as 4 GB, 8 GB, 16 GB, and 32 GB configurations.
Storage:
The system offers various storage options:
- PCIe SSD: Available in M.2 2230 and M.2 2280 form factors with up to 1 TB of capacity.
- SATA SSD: In M.2 2280 form factor with up to 512 GB of capacity.
- HDD: 2.5-inch SATA options with up to 1 TB capacity.
System Board Connectors:
The system board provides several connectors, including:
- M.2 2230 Key-E connector
- M.2 2280 Key-E connector
- M.2 3042 Key-B connector
Media Card-Reader:
The built-in media card reader supports MicroSD cards with a capacity of up to 2 TB.
Audio:
The system features a Realtek ALC3204 audio controller, supporting stereo conversion (24-bit DAC and ADC), and offers internal HD audio and external 7.1 channel audio via HDMI. The internal speakers are amplified and have an output of up to 2.5 W, with media-control shortcut keys available for external volume control.
Video Card:
Graphics are powered by the Intel UHD Graphics 620 for integrated graphics, supporting up to 4096 x 2304 resolution via HDMI 1.4b. The system also supports the AMD Radeon 540X discrete graphics with 2 GB of GDDR5 memory.
Camera:
The system includes an RGB fixed-focus HD camera with 1280 x 720 resolution for still images and video. Additionally, an optional IR camera with a 6 mm sensor is available, supporting Windows Hello for facial recognition.
Communication:
The network adapter supports Integrated Connection I219-V for 10/100/1000 Mb/s Ethernet and Intel XMM 7360 Global LTE-Advanced for mobile broadband. It also supports various wireless options like Intel Dual Band Wireless AC 9560 (802.11ac) and optional Wi-Fi 6 AX200 (802.11ax).
Ports and Connectors:
This system is equipped with:
- A microSD card reader
- A micro SIM card slot
- Three USB 3.1 Gen 1 (Type-A) ports
- One USB Type-C 3.1 Gen 2 port with DisplayPort/Thunderbolt 3 (optional)
- One HDMI 1.4b port
- One RJ-45 network adapter port
Display:
The display options include:
- 14-inch HD (1366 x 768) non-touch, antiglare screen with 220 nits of brightness.
- 14-inch FHD (1920 x 1080) wide viewing angle, antiglare screen with 220 nits (available in non-touch or optional touch variants).
The display has a contrast ratio of 700:1 for FHD and 400:1 for HD, with a typical brightness of 220 nits and a refresh rate of 60 Hz.
Keyboard:
The system features a full-sized QWERTY keyboard with 81 keys (US/Canada layout), and 82 keys (UK/Brazil layout). The keyboard is available in both backlit and non-backlit versions.
Touchpad:
The multi-touch touchpad supports up to 5-finger gestures, with a resolution of 1221 x 661 pixels. It measures 101.7 mm in width and 55.2 mm in height.
Fingerprint Reader (Optional):
An optional capacitive fingerprint reader is integrated into the power button with a resolution of 363 PPI, providing secure authentication.
Operating System:
The system supports several operating systems:
- Windows 10 Home (64-bit)
- Windows 10 Professional (64-bit)
- Ubuntu 18.04 LTS (64-bit)
- NeoKylin 6.0 SP4
Battery:
Battery options include:
- 3-cell lithium-ion (42 WHr), 3-cell lithium-ion (51 WHr), and 4-cell lithium-ion (68 WHr) batteries with ExpressCharge technology.
- Charging time varies, with the system supporting up to 1000 discharge/charge cycles for the LCL pack.
Operating time varies based on conditions and usage, and the battery is designed to function in a range of operating temperatures from 0°C to 50°C.
Power Adapter:
The system includes two power adapter options:
- 65 W adapter: Rated for 100-240 VAC input.
- 90 W adapter: Also rated for 100-240 VAC input.
