Certified Pre-Owned: Vetted based on “Like New” condition, 90-day minimum Seller-backed warranty , unlocked, fully functional with multi-point inspection & full data purge performed. The device looks new at first glance, upon close examination, it is possible to find some minor signs of wear.
Dell Latitude 7400 Technical Specifications
1. Chipset
- Chipset: CM246
- Processor: 9th Generation Intel Core i5/i7
- DRAM Bus Width: Dual 64-bit
- Flash EPROM: 24/32 MB (32 MB for Vpro SKU)
- PCIe Bus: PCIe 3.0
2. Processors
| Processor |
Wattage |
Core Count |
Thread Count |
Speed |
Cache |
Integrated Graphics |
| Intel Core i5-9300H |
35 W |
4 |
8 |
4.1 GHz |
8M |
Intel UHD Graphics 630 |
| Intel Core i5-9400H |
35 W |
4 |
8 |
4.3 GHz |
8M |
Intel UHD Graphics 630 |
| Intel Core i7-9850H |
35 W |
6 |
12 |
4.6 GHz |
12M |
Intel UHD Graphics 630 |
3. Memory
- Slots: Two SODIMM slots
- Type: Dual-channel DDR4
- Speed: 2666 MHz
- Maximum Memory: 32 GB
- Configurations Supported:
- 8 GB DDR4 (2 x 4 GB)
- 8 GB DDR4 (1 x 8 GB)
- 16 GB DDR4 (2 x 8 GB)
- 16 GB DDR4 (1 x 16 GB)
- 32 GB DDR4 (2 x 16 GB)
4. Storage
| Storage Type |
Interface |
Max Capacity |
| 2.5-inch HDD (5400rpm) |
SATA up to 6 Gbps |
1 TB |
| 2.5-inch HDD (7200rpm) |
SATA up to 6 Gbps |
1 TB |
| M.2 2230 SSD |
PCIe NVMe PCIe Gen3x2 |
512 GB |
| M.2 2280 SSD |
PCIe NVMe PCIe Gen3x4 |
1 TB |
| M.2 2280 SSD |
SATA Class 20 |
512 GB |
5. Ports and Connectors
External:
- Network: One RJ-45, 10/100/1000 Mbps
- USB:
- Two USB 3.1 Gen 1 ports
- One USB 3.1 Gen 1 with PowerShare
- One USB 3.1 Gen 2 (Type-C) with Thunderbolt
- Audio: One universal jack (headset + microphone + line-in support)
- Video: One HDMI 2.0 port
- Media Card Reader: One microSD slot (SD-card optional)
- Docking Port: Supported
- Power Adapter Port: One
- Security: Wedge-shaped lock slot
6. Dimensions and Weight
- Height: 20.4 mm (Front), 22.85 mm (Rear)
- Width: 323.05 mm
- Depth: 216 mm
- Weight: 1.53 kg (3.37 lb)
7. Display
| Type |
Resolution |
Panel Tech |
Luminance |
Color Gamut |
Touch Support |
| HD |
1366 x 768 |
TN |
220 nits |
45% (NTSC) |
No |
| FHD |
1920 x 1080 |
WVA |
220 nits |
45% (NTSC) |
No |
| FHD Touch |
1920 x 1080 |
WVA |
220 nits |
45% (NTSC) |
Yes |
8. Graphics
Discrete Graphics:
- Nvidia GeForce MX150 (TDP 25 W)
- Memory Size: 2 GB GDDR5 VRAM
Integrated Graphics:
- Intel UHD Graphics 630
- External Display Support:
- One HDMI 2.0 port
- Optional USB Type-C with VGA and DisplayPort support
9. Operating System
- Windows 10 Home (64-bit)
- Windows 10 Professional (64-bit)
- Windows 10 Pro for Workstations (64-bit)
- Red Hat 7.5
10. Communications
Ethernet:
- Integrated Connection I219-LM/I219-V Ethernet (RJ-45) with 10/100/1000 Mbps
Wireless Modules:
| Model |
Wi-Fi Standard |
Max Transfer Rate |
Bluetooth |
| Intel Dual Band Wireless AC 9560 |
WiFi 5 (802.11ac) |
1.73 Gbps |
Bluetooth 5.0 |
| Qualcomm QCA61x4A (DW1820) |
WiFi 5 (802.11ac) |
867 Mbps |
Bluetooth 4.2 |
| Intel AX200 |
WiFi 6 (802.11ax) |
2400 Mbps |
Bluetooth 5.0 |
11. Audio
- Controller: Realtek ALC3204
- Speakers: 2 (2 W average, 2.5 W peak)
- Microphone: Dual-array microphones
- External Interface: Universal Audio Jack
12. Battery & Power
| Battery Type |
Voltage |
Weight |
Charge Time |
| 3 Cell 51 WHr |
11.4 V |
250 g |
Express Charge: 2-3 hours |
| 4 Cell 68 WHr |
15.2 V |
340 g |
Express Charge: 2-3 hours |
| 4 Cell 68 WHr Long Cycle |
15.2 V |
340 g |
Express Charge: 2-3 hours |
Power Adapter:
| Type |
Voltage |
Current |
Connector Diameter |
| E5 90 W |
19.5 VDC |
4.62 A |
7.4 mm |
| E4 130 W |
19.5 VDC |
6.7 A |
7.4 mm |
13. Security
- Fingerprint Reader (Optional)
- Capacitive sensor
- 363 PPI resolution
- 7.4 mm x 5.96 mm sensor area
14. Camera
| Type |
Resolution |
Frame Rate |
Viewing Angle |
| RGB HD Camera |
1280 x 720 |
30 fps |
87° |
| Infrared Camera |
340 x 340 |
30 fps |
53° |
